Single Girder EOT Crane Manufacturer and Supplier
One of the most significant kinds of overhead cranes is the single girder model perfect for carrying light to medium-duty materials with a simple structure, light weight and an economical price.
Single girder EOT crane installations.
Single Girder EOT Crane Manufacturer
Bright Crane Equipment is a trusted single girder EOT crane manufacturer Ahmedabad. One of the most significant kinds of overhead cranes is the single girder model, which is perfect for carrying light to medium-duty materials.
A single main girder supported on both ends by end trucks, with a monorail trolley hoist hanging on the beam, makes up most single girder overhead cranes. With a simple structure, light weight, cost-effective shipping and an acceptable price, they are typically built in two configurations top running and under running with manual or electric monorail hoists to suit a variety of workshop and warehouse applications.
Single Girder EOT Crane Technical Specifications
| Parameter | Specification |
|---|---|
| Lifting capacity | 1 ton to 20 ton |
| Configuration | Top running or under running (underslung) |
| Girder | Fabricated box girder or rolled / profiled steel beam |
| Span | 10 m to 20 m (longer on request) |
| Lifting height | Up to 15 m |
| Hoist | Electric wire rope hoist; electric chain hoist for light loads up to 5 ton |
| Speeds | Lifting about 4 m/min; cross and long travel 10–15 m/min; dual speed or VFD optional |
| Duty class | M3 to M5 (Class I to II) as per IS 3177 |
| Motors & brakes | Dust-protected cage motors, brake-built-in (BBL) hoist motor option; electromagnetic / disc brakes |
| Power feed & control | C-rail festoon system; pendant or radio remote; 415 V, 3 phase, 50 Hz |
| Safety | Overload protection, limit switches, emergency brake |
| Standards | IS 807 and IS 3177 |
Economical, flexible and precise by design.
Most economical
For light to medium-duty bridge cranes, single girder cranes tend to be the most economical option.
Flexible mounting
Used with an engineered runway support structure, or running on top of pre-existing building columns.
Strong, simple frame
Box or profiled steel beams paired with mobile, motorised end carriages form the crane's framework.
Space-saving
Mounted high near the ceiling, the crane keeps your floor clear install it almost anywhere you need.
Precise controls
Extremely fine controls let operators position loads easily and accurately, minimising human error.
Applications of Single Girder EOT Cranes
Single girder EOT cranes suit any bay where loads stay within 20 ton and the crane needs to be economical and easy on the building structure.
What Sets Bright Crane Equipment Single Girder EOT Cranes Apart
Engineered details that deliver safe, accurate and dependable performance in everyday industrial use.
Single Girder or Double Girder: Which One Do You Need?
| Factor | Single Girder | Double Girder |
|---|---|---|
| Capacity | 1 to 20 ton | Up to 150 ton |
| Span | Up to about 20 m | Longer spans |
| Headroom needed | Less (hoist hangs below girder) | More hook height (crab runs on top) |
| Load on building | Lighter | Heavier |
| Cost | Lower | Higher |
| Best for | Workshops, warehouses, light-to-medium duty | Heavy fabrication, steel, high duty cycles |
Need more than 20 ton or a longer span? See our double girder EOT cranes, or compare every option on our EOT crane page.
Trusted by Leading Industries
Since 2007, Bright Crane Equipment has supplied cranes and hoists to public sector undertakings, defence manufacturers and private industries across India and 20+ export markets in Africa, the Middle East and South Asia.
Why Buy Your Single Girder EOT Crane from Bright Crane Equipment
- Built in Ahmedabad: designed and fabricated at our own works in Bakrol, Ahmedabad.
- In-house hoists: we manufacture our own wire rope and chain hoists, so spares and service are easy to get.
- Sized to your shed: we check your span, column strength and headroom before recommending top running or under running.
- Full scope: design, manufacturing, supply, installation and commissioning, with after-sales support and emergency service lines.
- Since 2007: trusted by PSUs, railways and private plants across India.
Frequently Asked Questions
Q. Can a single girder EOT crane be installed in an existing shed?
Yes, in most cases. A top running crane can sit on runway beams fixed to your existing columns, if the columns can take the load. If your shed has no suitable columns, an under running crane can hang from the roof structure. Our engineers check the column strength, span and headroom at site before suggesting the right option.
Q. How much does a single girder EOT crane cost?
The price depends mainly on capacity, span, lifting height, hoist type and controls (standard or VFD). Runway beams, rails and installation are usually quoted separately. Share your requirement for an exact quote, or read our EOT crane price guide to understand the cost factors.
Q. How long does delivery and installation take?
A standard single girder EOT crane usually takes 3 to 5 weeks to manufacture after drawing approval. Installation and commissioning at site takes 2 to 4 days, provided the runway and power supply are ready.
Q. Do you provide service and spare parts after installation?
Yes. We provide after-sales service, emergency breakdown support and spare parts such as hoists, bottom blocks, festoon systems and end carriages, most of which we manufacture in-house.
Talk to our engineering team.
Share your lifting requirement and our team will help you plan the right single girder crane configuration.
